| 3ds max and vrayies lights used to light the retail store unit I have created for a client |
VRayIES
VRayIES lights are often used to recreate existing artificial light profile distributions, for interior scenes.
Companies such ERCO and Color Kinetics have a host of exiting IES light profiles ready for download:
https://www.erco.com/download/en/
https://www.colorkinetics.com/global/support/ies
This article about ies lights is a small excerpt from my new book with Taylor and Francis/CRC Press, entitled: V-Ray 5 for 3ds Max 2020: 3D Rendering Workflows
For more information about my new book, please check the link directly below:
 |
| V-Ray 5 for 3ds Max 2020: 3D Rendering Workflows |
http://jamiecardoso-mentalray.blogspot.com/2021/05/v-ray-5-for-3ds-max-2020-3d-rendering.html
To create a VRayIES light, use some of the steps described earlier, and refer to my other tutorial about, setting up your Initial 3ds Max scene.
https://jamiecardoso-mentalray.blogspot.com/2020/09/v-ray-5-setting-up-your-initial-3ds-max.html
Followed by selecting the VRayIES button, clicking the cursor in the Front/Left viewport , and dragging it down to create it.
Right click to exit light creation
 |
| < Creating a VRayIES light in the viewport> |
Once the VRayIES light has been created (with its target facing downwards), users can disable the Targeted function, to move the VRayIES light.
Most of the VRayIES parameters are self-explanatory. The following discussion will focus mainly on the most important ones.
 |
| <VRayIES light parameters> |
Enable- It enables the light to be turned On, or Off.
Show distribution- It shows the distribution of the IES light in the viewport.
IES file-This toggle allows users to locate and plug IES light profile.
IES web profiles are based on a real-world light distribution. IES 14 is one of the most popular light profiles used to create patterns of pools of light on the floor, and walls.
Note: IES 14 is included in the book resources.
 |
| < IES web file 14 loaded from dialog> |
To preview the IES distribution in the shaded viewport, simply click on the User Defined text, and choose the Light and Shadows option.
Followed by choosing to, Illuminate with scene Lights.
 |
| < User viewport option to Illuminate with scene Lights> |
 |
| < Results of Illuminate with scene Lights in the viewport> |
If you happen to have a good graphics card, enable the V-Ray Viewport IPR (Interactive Production Rendering) to display a fast and accurate preview of the final render in the viewport.
 |
| < User viewport option to choose the V-Ray Viewport IPR > |
Affect diffuse- This function determines whether the IES light will affect the diffuse color of objects, or not.
Enabled, by default.
Diffuse contribution-This function controls the intensity of the lights on the diffuse color of objects.
Default value, 1.0
Affect specular- This function determines whether the IES light will affect the specular/glossiness of objects, or not.
Enabled, by default.
Specular contribution- This function controls how much the IES light will affect the specular/glossiness of objects.
Default value, 1.0
Use light shape-This function controls how the shape of the light will be factored in to process the shadows and the illumination.
For shadows only, is used by default.
Override shape-If chosen, it disables the IES profile shape, and enables functions such as, Shape, Height, Width, Length and Diameter.
Override Intensity-This function controls how the IES light intensity will be used.
Rescale-This function matches the light intensity defined by the user.
Replace-This function recalculates(multiplies) the intensity based on the IES distribution.
Intensity type- This function determines the units of the light intensity.
Intensity value - This function controls the intensity of the IES light.
 |
| < VRayIES light Intensity value set to 2500.0> |
 |
| < Render result of Intensity value set to 2500.0> |
 |
| < Intensity value IES power set to 17800.0> |
 |
| < Render result of Intensity value set to 17800.0> |
To light up a fairly spacious scene it is recommended to create multiple ies lights. I often copy/instance (Ctrl+v) ies lights across the scene to speed up the rendering process substantially.
 |
| Instance Clone Options enabled |
 |
| Final render with vrayies lights |
To download professional IES profiles, simply click on my google drive link below.
https://drive.google.com/drive/folders/1bQAivGC2n73Zjmqm0208OMIXYnK7OjxS?usp=sharing
Alternatively, you can create customised ies light profiles by using a plug-in called, Creator IES .
To download it, please click on my google drive link below:
https://drive.google.com/file/d/1ZZmkb1-RbrhaFqB6KIYBpYt5tKDywDah/view?usp=sharing
For more information on how to use this plug-in, please check my tutorial link below:
http://jamiecardoso-mentalray.blogspot.com/2012/12/creating-customised-ies-web-lights-for.html
I hope you have found this small excerpt useful.
Ta
Jamie
P.S: Take care and Stay Safe
